HomeIndustrial & ScientificIndustrial ElectricalControls & IndicatorsRelaysOverload Relays1Pcs Single 24V Relay Isolated Drive Control Module High level drive board
/product/16/3255914/1.jpg?6118)
Share this product
₦ 7,000
1 units left
+ shipping from ₦ 1,700 to LEKKI-AJAH (SANGOTEDO)
0 out of 5
(No ratings available)Promotions
Delivery & Returns
Choose your location
Pickup Station
Delivery Fees ₦ 1,700
Ready for pickup between 23 September and 24 September if you place your order within the next 14hrs 48mins
Door Delivery
Delivery Fees ₦ 2,750
Ready for delivery between 23 September and 24 September if you place your order within the next 14hrs 48mins
Return Policy
Free return within 7 days for ALL eligible itemsDetails
Seller Information
PIERTOELECT.NIG.LIMITED
80%Seller Score
30 Followers
Seller Performance
Shipping speed: Excellent
Quality Score: Excellent
Customer Rating: Very Poor
Cancellation Rate: Excellent
Product details
The relay isolation drive control module,the core is an electronic control device relay,with a control system (also known as an input loop) and a controlled system (also known as an output loop),which is essentially a "automatic switch that uses a smaller current to control a larger current" ". Used to control 10A 250V AC,10A 30V DC load,with output signal indicator. Adopt dual power supply selection design to enhance anti-interference ability. Therefore,it plays the role of automatic adjustment,safety protection and conversion circuit in the circuit.
Product characteristics:
1. With output signal indicator
2. The signal input port can be connected to the single-chip IO port,driven by high-level signals
3. Dual power supply design,strong anti-interference ability,photoelectric isolation protection and high reliability.
4. Onboard 3V,10A/250VAC; 10A/30V DC relay. Can be continuously attracted 100,000 times,with diode discharge protection,short response time
5. The external connection adopts rotary crimping terminal to make the connection more firm
6. With fixed mounting holes for easy installation
Interface Description:
Power interface:
VCC: Connect to the positive pole of the power supply (3.3V)
GND: Connect to the negative pole of the power supply
IN: high level control relay pull-in
Load interface:
NO: Normally open interface of the relay,the relay is suspended before pull-in,and shorted to COM after pull-in
COM: Relay common interface
NC: Normally closed interface of the relay,the relay is short-circuited with COM before pull-in,and hangs up after pull-in
View more
Specifications
Key Features
Interface Description:
Power interface:
VCC: Connect to the positive pole of the power supply (3.3V)
GND: Connect to the negative pole of the power supply
IN: high level control relay pull-in
Load interface:
NO: Normally open interface of the relay,the relay is suspended before pull-in,and shorted to COM after pull-in
COM: Relay common interface
NC: Normally closed interface of the relay,the relay is short-circuited with COM before pull-in,and hangs up after pull-in
Specifications
- SKU: GE779IP6VVAVRNAFAMZ
- Weight (kg): 1.0kg
- Color: GREEN
