HomeMusical InstrumentsStudio Recording EquipmentComputer RecordingAudio Interfaces Scarlett 18i20 Usb-c Audio/midi Interface - 4th Generation
/product/97/5336914/1.jpg?3380)
/product/97/5336914/2.jpg?3380)
/product/97/5336914/3.jpg?3380)
/product/97/5336914/4.jpg?3380)
/product/97/5336914/5.jpg?3380)
Share this product
Brand: Focusrite | Similar products from Focusrite
₦ 1,600,000
5 units left
+ shipping from ₦ 1,700 to LEKKI-AJAH (SANGOTEDO)
0 out of 5
(No ratings available)Promotions
Delivery & Returns
Choose your location
Pickup Station
Delivery Fees ₦ 1,700
Ready for pickup between 25 September and 28 September if you place your order within the next 22hrs 33mins
Door Delivery
Delivery Fees ₦ 2,750
Ready for delivery between 25 September and 28 September if you place your order within the next 22hrs 33mins
Return Policy
Free return within 7 days for ALL eligible itemsDetails
Seller Information
Delitstore
New Seller
4 Followers
Seller Performance
This seller does not have enough history for us to evaluate his performance yet
Product details
Focusrite Scarlett 18i20 4G Specs
Key Specs
| Channels of I/O | 18 Inputs / 20 Outputs |
| Maximum Sampling Rate | 192 kHz / 24-Bit |
| Number of Microphone Inputs | 8 |
| Analog Audio I/O | 2x Combo XLR-1/4" TRS Mic/Line/Hi-Z Input 6x Combo XLR-1/4" TRS Mic/Line Input 10x 1/4" TRS Line Output 2x 1/4" TRS Headphone Output |
| Digital Audio I/O | 2x ADAT Input 2x ADAT Output 1x S/PDIF Input 1x S/PDIF Output |
| Host Connection | 1x USB-C (Class-Compliant) |
| Power Requirements | AC Input |
General
| Display | No |
| Channels of I/O | 18 Inputs / 20 Outputs |
| Built-In DSP | No |
| Maximum Sampling Rate | 192 kHz / 24-Bit |
| Number of Microphone Inputs | 8 |
| Built-In Microphone | Yes |
| Input Level Adjustment | 8x Knob |
Signal Processing
| Pad | No |
| Gain/Trim Range | Mic/Line Inputs: 69 dB Hi-Z Inputs: 62 dB |
| High-Pass Filter | No |
| Solo/Mute | No |
Connectivity
| Analog Audio I/O | 2x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line/Hi-Z Input (Front Panel) 6x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line Input 10x 1/4" TRS Line Output 2x 1/4" TRS Headphone Output |
| Phantom Power | 48 V, Selectable On/Off |
| Digital Audio I/O | 2x TOSLINK Optical ADAT Input 2x TOSLINK Optical ADAT Output 1x RCA Coaxial S/PDIF Input 1x RCA Coaxial S/PDIF Output |
| Host Connection / USB | 1x USB-C (Class-Compliant) |
| Host Connection Protocol | USB 2.0 |
| USB (Non-Host) | No |
| Sync I/O | 1x BNC Word Clock Output |
| Network I/O | No |
| MIDI I/O | 1x DIN 5-Pin Input 1x DIN 5-Pin Output |
| Expansion Slots | No |
| Wireless | No |
Performance
| Frequency Response | Mic Inputs: 20 Hz to 20 kHz ±0.06 dB Line, Hi-Z Inputs: 20 Hz to 20 kHz ±0.05 dB Line Outputs: 20 Hz to 20 kHz ±0.02 dB Headphone Outputs: 20 Hz to 20 kHz ±0.1 dB (at 33 / 300 Ohms) |
| Maximum Input Level | Mic Inputs: 16 dBu Line Inputs: 22 dBu Hi-Z Inputs: 12 dBu |
| Maximum Output Level | Line Outputs: 16 dBu Headphone Outputs: 16 dBu |
| Headphone Output Power | 57 mW into 33 Ohms 27 mW into 300 Ohms |
| Impedance | Mic Inputs: 3 Kilohms Line Inputs: 24 Kilohms Line Outputs: 200 Ohms Hi-Z Inputs: 1 Megohm Headphone Outputs: 11 Ohms |
| Dynamic Range | Hi-Z Inputs: 113 dBA Line Inputs: 115.5 dBA Mic Inputs: 116 dBA Headphone Outputs: 112 dB (at 33 Ohms) 116 dB (at 300 Ohms) Line Outputs: 122 dBA Digital A/D Converters: 120 dBA Digital D/A Converters: 130 dBA |
| THD+N | Mic/Line Inputs: -100 dB (at 8 dB Gain) Hi-Z Inputs: -80 dB Line Outputs: -112 dB Headphone Outputs: -100 dB (at 33 Ohms) -110 dB (at 300 Ohms) Digital A/D Converters: -110 dB Digital D/A Converters: -115 dB |
| EIN | Mic Inputs: -127 dBu A-Weighted |
Digital Audio
| Sample Rates | 44.1 to 192 kHz |
| Sample Rate Conversion | No |
| Bit Depths | 24-Bit |
| Sync Sources | ADAT, Internal, S/PDIF |
Audio Storage & Playback
| Media/Memory Card Slot | No |
Compatibility
| OS Compatibility | Computer: macOS / Windows Mobile: Android/iOS |
Specifications
Key Features
Power
| Power Requirements | AC Input |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| Power Consumption | 30 W |
Physical
| Rackmount Size | 1 U (with Included Hardware) |
| Operating Conditions | 47 to 104°F / 8 to 40°C |
| Dimensions | 17.4 x 10.2 x 1.8" / 44.2 x 25.9 x 4.6 cm |
| Weight | 7.3 lb / 3.3 kg |
Specifications
- SKU: FO662MI887VGBNAFAMZ
- Weight (kg): 1
