e-Ink Micro Mini 10/100/1000BASE-T SFP Media Converter

• Auto Sensing 100/1000Base-FX: The SFP fiber port supports 100/1000Base-FX, auto detect. You can choose 155M or 1.25G SFP module accordingly
• Ultra Compact: This SFP fiber media converter size is 3.11x10.6x0.71 inch, even smaller than other similar ultra compact design. Suitable for installation and integrated in other equipment such as IP camera housing. It’s suitable for tight space
• Aluminum Housing: Use high quality aluminum material with surface brushed process. The Ethernet media converter has good heat dissipation performance. It’s not just have delicate appearance but also strong and durable
• USB Power Input：This SFP fiber media converter uses Type-C port for power input, with USB cable and power adapter included. You can simply use USB port on PC to power this device. Also you can use the AC-DC 5V adapter
• SM 20Km SFP Module：The Ethernet media converter comes with duplex single-mode 1310nm 20km SFP module

Access mode: 10/100/1000Mbps Gigabit Ethernet
Standard:
IEEE802.3 10Base-T Ethernet
IEEE802.3u 100Base-TX/FX Fast Ethernet
IEEE802.3ab 1000Base-T
IEEE802.3z 1000Base-SX/LX Gigabit Ethernet

Power supply: DC 5~15V (Type-C)
Power consumption: <3W
Operating temperature: 0~45ºC
Operating humidity: 5%~90%
Maintaining temperature: -40~70ºC
Maintaining humidity: 5% ~ 90% non-condensing
Weight: 46g
Dimensions (W x D x H): 78 x 27 x 18 mm
